K2 Panel Radiators

Please use the chart below to select your k2panel radiator

  Heights
Length 12"
300		 16"
400		 20"
500		 24"
600		 30"
750
15.7"
400		 1494 / 438£156.08 Buy Now 1853 / 543£138.74 Buy Now 2184 / 640£131.42 Buy Now 2491 / 730£190.41 Buy Now 2921 / 856£206.46 Buy Now BTU / Watts
Price
20.4"
520		     2839 / 832£201.62 Buy Now 3241 / 950£238.16 Buy Now 3777 / 1107£272.60 Buy Now BTU / Watts
Price
23.6"
600		 2242 / 657£221.15 Buy Now 2777 / 814£194.78 Buy Now 3276 / 960£220.38 Buy Now 3740 / 1096£257.64 Buy Now 4384 / 1285£294.65 Buy Now BTU / Watts
Price
28.3"
720		     3931 / 1152£258.44 Buy Now 4487 / 1315£293.13 Buy Now 5261 / 1542£347.26 Buy Now BTU / Watts
Price
31.5"
800		 2989 / 876£297.86 Buy Now 3705 / 1086£260.56 Buy Now 4367 / 1280£293.29 Buy Now 4985 / 1461£333.08 Buy Now 5845 / 1713£392.44 Buy Now BTU / Watts
Price
36.2"
920		     5022 / 1472£334.01 Buy Now 5732 / 1680£372.11 Buy Now 6722 / 1970£447.42 Buy Now BTU / Watts
Price
39.4"
1000		 3736 / 1095£347.85 Buy Now 4630 / 1357£302.62 Buy Now 5459 / 1600£350.17 Buy Now 6230 / 1826£412.20 Buy Now 7305 / 2141£488.64 Buy Now BTU / Watts
Price
44.1"
1120		     6114 / 1792£399.41 Buy Now 6978 / 2045£450.66 Buy Now 8182 / 2398£532.94 Buy Now BTU / Watts
Price
47.2"
1200		 4470 / 1310£416.75 Buy Now 5555 / 1628£374.16 Buy Now 6551 / 1920£438.89 Buy Now 7476 / 2191£490.66 Buy Now 8765 / 2569£655.80 Buy Now BTU / Watts
Price
52"
1320		     7206 / 2112£472.21 Buy Now 8223 / 2410£549.15 Buy Now 9642 / 2826£717.47 Buy Now BTU / Watts
Price
55.1"
1400		 5231 / 1533£489.95 Buy Now 6483 / 1900£430.78 Buy Now 7643 / 2240£492.85 Buy Now 8721 / 2556£633.27 Buy Now 10226 / 2997£758.66 Buy Now BTU / Watts
Price
63"
1600		 5978 / 1752£550.71 Buy Now 7407 / 2171£487.17 Buy Now 8735 / 2560£557.66 Buy Now 9970 / 2922£729.55 Buy Now 11690 / 3426£858.67 Buy Now BTU / Watts
Price
70.9"
1800		 6725 / 1971£625.56 Buy Now 8336 / 2443£535.60 Buy Now 9827 / 2880£622.20 Buy Now 11215 / 3287£817.52 Buy Now 13150 / 3854£974.97 Buy Now BTU / Watts
Price
78.7"
2000		 7472 / 2190£686.26 Buy Now 9260 / 2714£680.77 Buy Now 10918 / 3200£778.73 Buy Now 12461 / 3652£904.46 Buy Now 14610 / 4282£1,084.28 Buy Now BTU / Watts
Price
86.6"
2200		 8220 / 2409£782.33 Buy Now   12010 / 3520£889.15 Buy Now 13706 / 4017£1,036.76 Buy Now   BTU / Watts
Price
94.5"
2400		 8967 / 2628£887.63 Buy Now   13102 / 3840£1,003.50 Buy Now 14951 / 4382£1,158.01 Buy Now   BTU / Watts
Price
102.4"
2600		 9714 / 2847£955.43 Buy Now   14194 / 4160£1,084.28 Buy Now 16200 / 4748£1,260.07 Buy Now   BTU / Watts
Price
110.2"
2800		 10458 / 3065£1,020.68 Buy Now         BTU / Watts
Price
118.1"
3000		 11208 / 3285£1,101.34 Buy Now         BTU / Watts
Price

Heat outputs based on a mean radiator water temperature of 70° and room temperature of 20° Delta T50
